Wayneo

I don't think so. Your second 'firing' in the last printscreen already showed 2.68v with a dip even lower. Usually, or in my case, at that wattage on a single battery DNA75, not color, I've seen around .6-.8 voltage drop, all depending (like retird) said on battery and connections. I don't think the mod is too advanced for you at all. Especially not in wattage mode. By 'advanced' it has actually helped you/us to identify where the problem may lie, instead of just being blind. Please keep us informed with your dealings with them.

How high is it? Have you checked in AA on another DNA mod? or tried a different rda? Check your grounding, and solder joints.

Did you ask Boxer if this was normal for their mods? That Black line shows your battery is sagging from ~3.7v to your 2.5v CSC, and the internal temp has risen 100F. Volts are way better than %'s to diagnose issues.

@Toffi69 I'd download the dna datasheet, and the back pages are the board measurements/details. I'd measure the actuator placements first and screen dimensions to get an idea of what you could be getting into

Do you already own the Hugo Boxer Mod?

Not me, my man, but I'll take it for pointing you in the right direction. Go 'like' TheSwain's post so others can see you agree. As far as mod resistance you might wanna search around here. I don't own one, they can all be different, and now that you've removed that loctite .......... well?

@PepeSilvia Easy answer ...... Yes to everything. It's a simple 2 column csv showing Battery Charge %, and the voltage. Only affecting the display gauge. Depending on your vaping characteristics you'll get different usage results in real life. In general, you'll get better results with a serial board

You can use that one

Kanthal is good ole watts usage. So whatever the ratings on the coil. There are also 0.4Ω SS316L (Stainless Steel Coil for Temperature Control) Enjoy your mod

Here's a great post written by an Evolv tech

You can create or load your own battery curve which only affects the gauge display in combination with Watt hours input. Cell soft cutoff for message when you're hitting that 'lower' limit. Soft being the keyword which is the big momentary dip when you first hit the fire button.

General/Power: Kanthal power limit <- 'Your' manual limiting of max watts. Preheat power <- TC only Preheat punch <- TC only There are some good youtube escribe tutorials by pbusardo and djlsb vapes.

It's not a regular 510 connector like you'd imagine. I have seen conversions done with a FatDaddy :ow profile, which IIRC had an 11mm depth. I saved this post from long ago, as it's the same enclosure. https://www.e-cigarette-forum.com/threads/replacing-the-510-in-an-rx200-fairly-easy-actually.727725/

Can you do a Printscreen of the 'Screen' tab in escribe, while your mod is plugged in .

Those are all the standard Evolv defaults, and any 3 battery mod will work fine using them straight out of the box. Battery - You can create or load your own battery curve which only affects the gauge display in combination with Watt hours input. Cell soft cutoff for message when you're hitting that 'lower' limit. Case thermals - Mainly for TC usage, but also useful for when your batteries are getting old and heating up. Mod resistance - Mainly for the most accurate coil resistance readings, especially for TC usage.

Unfortunately no, they're parallel. And IIRC in the datasheet advertised as integrated charging, and neither balance or balanced is in the entire document. Welcome

The 75's batteries are all in a parallel configuration so presented to the board/chip as 1 cell, whether it's one or more cells.

For a completely clean file, on the front page when you start escribe it's right there as 'Evolv dna 250'.

Was it ever any brighter than now? If it was NOT, there could be a smoky covering over the display.

Search works, and there are many sharp experienced users here. IMHO, public is better cuz if any of us are wrong someone will catch it quickly. Welcome

Well yes. And Defaults refers to Evolv's generic defaults. Edit: Unless the vendor has used the 'Production Utility' to program the board, in which case, it would actually be back to where it all was when shipped to you. BUT you're in luck because when you've fired up Escribe, under the 'help' menu item, down at the bottom, you'll see a 'backups' item, and it's saved a full copy everytime you started escribe.

For that form factor, I'd guess Lipo, with a 4S, unless they put a new higher fuse on the board

I can understand your frustration, and it's understandanable for new users of escribe. If you're willing to give it one last shot you can try this. Hold + and - for a few seconds till you see a 'power locked' message. Quickly push either + or - twice to put you into profiles mode. Press + once and it will change to the next profile, and for each subsequent press, and will round robin through all 8. One of the three you said you had should say something like power or watts or kanthal. When you find the one you think sounds right, hit the fire button to choose it. Hold + and - for a few seconds till you see a 'power locked' message. You should now have watts showing dominant, and change it up or down There are some good escribe tutorials on youtube you should watch once it's back working.

Well, your board does have a real 1 year warranty from Evolv, and if you open a trouble ticket they'd guide you. EVOLV HELP DESK - https://helpdesk.evolvapor.com/?a=add

No idea at all. Here's a screenshot with my Lipo JST unplugged. No icon on screen. Mode shows normal, all cells show '0', and small USB current. Are you sure you're replacing that connector where the OG was plugged in? I haven't seen the internals of a VS.
