@dwcraig1 Understood. Thank you for response.

Unfortunately that didn't work. What also did not work: ECig['USB Current'] = 0.0 The only parameter available out of 3 (current, power & voltage) is voltage (5V in my case) - it's not possible to change that either, only read (understandable though). Dissapointing. I've specifically ordered the most modern DNA board mod in hope all of the features I read on this forum are going to be there. The mod is capable of charging through USB-C, yet you cannot control the USB current unlike older board versions. P.S. regarding not being able to connect board as CDC device ESP32-S2 - it's possible, just had to ground USB-ID GPIO pin for ESP32 talking USB host mode and turn on VBUS GPIO pin so that DNA board wakes up and enumerates itself.

I don't see such options on DNA60C (Cthulhu Sentinel). None of mentioned menus exist in my Escribe: "Device Monitor - Diagnostics - Disable USB Charging" ❌ escribe -> mod -> battery tab - Max USB Charge Rate: 1.5 ❌ Please help me locate the menu. Serial command would be OK too. More info: I'm using a ESP32-S2 board trying to read stats from DNA60C by reading it as CDC device. Seems like current/voltage from ESP32 is not enough to make mod become available as CDC device (at least to show charging status). This is why I want to try disabling USB charging.

1. Did you find the connection between mod and RPI to be stable? 2. Did you use some special OTG cable (micro USB to USB 2.0) or just regular data transfer cable? P.S. Nice looking project! Good job!

In DM with @Wayneo I asked: Wayneo replied: Oh, I just looked at first SS coil I could find, not realizing that there are different geometries of coils - I'm a newbie here - now I see that I probably need Fused Clapton geometry. RTA I want to put this on (Fat Rabbit RTA Solo 2) comes by default with ID 3.0mm 0.37 ohm Ni80 Clapton coil (not sure about other specs). So just Clapton - not Fused Clapton (not sure if critical) So now is the following coil likely going to suit my needs with Replay & TC on DNA60c mod? FUSED CLAPTON 316L 2-26/38GA Ø3.00mm 0.29Ω

I ended up choosing to go with full DIY RTA - harder on start, cheaper and future proof and easier to find coils down the road. Most pre-built coils like Vaporesso GTI are made of Kanthal/Clapton - not good for replay/TC - only basic wattage mode.

I plan on buying DNA60C chip mod and to fully experience its temperature control or Replay features I need SS coils. I don't want to dive into full DIY coil - I need pre-built coils suitable for MTL. I looked into Vaporesso xTank T that supports GTX coils, but the material there is Kanthal - does not support TC. I need SS - seems to be the best TC experience with DNA chips. There's also Vaporesso EUC-Keramik SS316 0,6 Ω 40–55 W, but I'm not sure what tank will suit it best and whether the quaility is good. Please recommend budget tank + pre-built SS coils. Thank you!

I wonder if Zenith M is compatible, because otherwise why the heck would Innokin Sidera DNA60C ship their mod with Zenith M installed.

By reading forum I came to conclusion that DNA80C might have limited Escribe config options compared to other boards. I guess it has something to do with TC options. That leads me to suspicion that Serial commands support is also not full in other areas, not only TC. I don't have 80C device yet, so I would like to ask on forum before buying one about command availability on DNA80C based on unofficial supported command list I found on Github. - Do you guys know which of these commands might not be supported on DNA80C? - If answer is not trivial, can you at least tell me if following 2 are supported? S=GET PUFFS & P=<number>W (Set power).
