GrumpiTurnip

yes something is wrong somewhere, ive just soldered the 510 when checking with a meter earth and 510 pin no fire button pressed im getting voltage of 3.2v then press the fire button and no change, Ok it looks like im gonna have to pull it all out and see whats happening, Hopefully i notice something this has totally baffelled me. Thankyou both @dwcraig1 @Wayneo for your time and patience i will start testing connection when i get a bit more time and hopefully have a good outcome

80c connected straight away so then plugged the 60c back in but Nope wont recognise it

Yes it connected to escribe prior to installation i am about to try my DNA 80c

I'm using escribe 2 sp57 international on windows, Downloaded from the evolv website. Just been out and purchased a data cable but still no joy, the red led comes on the charging board but wont recognize the board.

Edit : So I've now mounted the board and type c board in place, I am running 2x18350 Batteries in parallel, plugged it into escribe and it will not recognise the board saying please connect a device 🤔 All I have left to connect is the 510 - and + with the batteries inserted i put a meter on the positive and negative and without pressing the fire button it's showing 3.2v when I press the fire button there is no change in the voltage. I have spent hours building the mod and searching the forum for an answer but to no avail, would anybody have any ideas or suggestions please I'm about to call it a day as it's eating into my long weekend off work. Have attached some pics...... Cheers Simon

Thankyou for your replies @Wayneo @dwcraig1 now ive calmed down and went searching the forum i read a post about escribe cant connect without a battery connected, the only thing i didnt try and low and behold she lives. Least i know my connections are good after resoldering everyone 😄

Hi all I making my own mod have soldered everything where I believe it should be using a 2amp charging board for the dna60c, plugged it into escribe it detected the board then said no device connected. Have tried several USB cables but no difference, it connected one time started to up load the settings and stopped at 6% and wont go no further and escribe just has the spinning wheel I can't even Close escribe. I'm using windows 10, Any help would be appreciated as I am gutted was the last thing to do to complete the build. Have attached a pic below just incase someone can see something I've missed Cheers Si

Im not the best person to be able to explain a problem and should of put in more information, i have heard of a cold solder joint in the past, hoping its not that. i have attached a picture ( hopefully it works) of the mod. Shame because its a great mod. Thank-you for your time 😊 C0291407-B97A-4676-AE09-C50C68A7D769.webp

Yes i dowloaded the theme so i had replay if i wanted to use it but in the watts profile i use for n80 i disable replay, Sorry for the confusion will edit post.

I don't have replay turned on in escribe for that profile !

It goes in one full turn then starts reading ohms, reads 1.2 ohms and all the way in it reads 1.076

Ok i done the atomizer analyzer before firing it.... Ohms 1.067 Raw Ohms 1.071 Mod Resistance 0.004 Room Temp 67.41°F When fired showed the check atomiser twice and now works fine, hope this helps.

I thought it best to do it before as thats when the problem is. Yes this has happened from day one, only had it 6 weeks. Thought it maybe the theme so changed it as i wasn't keen on it anyway.

Will do this when i get home from work, should i do this before i fire the mod ? Sorry don't know how to post findings but will have a look.

The atty is a 24mm Dvarw The coil is a MTL clapton all ni80 (pc coils) Sorry how would i find room temp for mod & atty ? Battery contacts are all clean.
